Flameproof Hooter with Beacon

Name: Flameproof Hooter with Beacon
Brand: HIMALAYA ENGINEERS
Price: 9500.0 INR
Availability: InStock

Price 9500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

Flameproof Hooter with Beacon Specification

Protection Level
IP66

Base Material
Other

Thickness
5 Millimeter (mm)

Cover Material
Other

Rated Operation Voltage
230 V AC

Product Type
Switchgear

Surface Finish
Powder Coated

Standard
IEC 60079

Surface Color
Other

Rated Voltage
230 /24 AC Volt (V)

Frequency (MHz)
50 Hertz (HZ)

Usage & Applications
Hazardous Area

Dimension (L*W*H)
300*200*200 Millimeter (mm)

Frequency
50 Hertz (HZ)

Material
Cast Aluminium

Warranty
1 Year

Application
Industrial

IP Rating
Ip55

Flameproof Hooter with Beacon Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Baroda

Payment Terms
Others

Supply Ability
5 Pieces Per Day

Delivery Time
2 Week

Sample Available
No

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
corrugated Box

Main Export Market(s)
Asia

Main Domestic Market
All India

Certifications
ERTL & PESO

About Flameproof Hooter with Beacon

FLP/WP Hooter with Flashing Beacon with Acknowledgement

Exd IIA IIB As per IS/IEC 60079-1:2007 & IS/IEC 60079-0:2004

Ingress Protection: IP 66
Temperature Classification: T6
HOOTER & FLASHING LIGHT
Electrical Rating: 230 V AC
Sound output: SPL at 1KHz 110dB
Impedance: 8 Ohms.
Frequency Response: 300-5000 Hz
Electrical Rating: 230 V Ac
Red High intensity flash light - Flash Frequency 100 FPM
Accept Button: Built in sound accept circuitry
Glass - Heat and impact resistance toughened Type A
Cable Entry: 2 nos - 3/4" ET
Earthing: 1 no inside & 2 nos. External
Terminal: 2 Way terminal block
Mounting: Wall mount

Engineered for Hazardous Locations

This flameproof hooter with integrated beacon is specifically developed for environments where safety from sparks and explosions is essential. Certified under IEC 60079, its sturdy construction and IP66/IP55 ratings ensure high resistance to dust, water, and impacts, making it a dependable choice for industrial hazard zones.

Key Technical Features

With a robust 5 mm cast aluminium build and powder-coated surface, the unit endures tough conditions. It operates at either 230V AC or 24V AC and measures 300x200x200 mm, providing flexibility in installation. The device supports dual-function signaling-audio from the hooter and visual from the beacon-ensuring effective alerts.

FAQ's of Flameproof Hooter with Beacon:

Q: How should the Flameproof Hooter with Beacon be installed in hazardous industrial areas?

A: The device must be fixed securely in an appropriate location where potential hazards are present. Ensure power supply compatibility with either 230V AC or 24V AC as specified, and allow enough space for the 300x200x200 mm dimensions. Installation should always comply with local electrical safety and IEC 60079 standards.

Q: What benefits does the cast aluminium construction provide for this hooter and beacon?

A: Cast aluminium offers excellent mechanical and thermal strength, providing robustness against physical impacts, corrosion, and high temperatures, making it ideal for challenging industrial environments.

Q: When is it appropriate to use this flameproof hooter and beacon in industrial settings?

A: It is best used whenever there is a need to provide clear visual and audible warnings in hazardous locations, such as chemical plants, oil refineries, and production facilities where explosive gases or dust may be present.

Q: Where can this product be sourced in India?

A: This product is available through authorized dealers, distributors, exporters, suppliers, and traders across India, ensuring accessibility and support for industrial applications nationwide.

Q: What is the process for regular maintenance of the flameproof hooter and beacon?

A: Regular maintenance includes periodic checks for external integrity, cleaning of the powder-coated surface, and ensuring all electrical connections are secure. Always switch off power before servicing, and follow the manufacturer's maintenance guidelines.

Q: How does the IP66/IP55 protection rating enhance product reliability?

A: These ratings indicate high resilience against dust and water ingress, which means the hooter and beacon remain functional in harsh, wet, or dusty environments, reducing the risk of failure due to environmental factors.
